Themba Nickel Alloys in Cape Town, Cape Town, is a reliable manufacturer and exporter of Incoloy 800, 800H, and 800HT flanges. With their high precision engineering and superior quality, the flanges are capable of performing well under high temperatures as well as high corrosive environments. Themba Nickel Alloys provides products up to international standards, catering to markets in petrochemical, power generation, and heat treatment industries. With a heavy emphasis on performance and durability, the company supplies Incoloy flanges that provide secure and safe piping connections for high-performance critical systems under thermal and mechanical stress.
Specifications : ASTM B 564 / ASME SB 564
Dimensions : ANSI B16.5, ANSI B16.47 Series A & B, MSS SP44, ASA, API-605, AWWA, Custom Drawings
Standards : ANSI Flanges, ASME Flanges, BS Flanges, DIN Flanges, EN Flanges etc.
Size : 1/2″ to 36″
Pressure Rating : Class 150, Class 300, Class 400, Class 600, Class 900, Class1500, Class 2500 | PN6, PN10, PN16, PN25, PN40, PN64 etc.
Flange Face Type : Flate Face (FF), Raised Face (RF), Ring Type Joint (RTJ)
| C | Mn | Si | S | Cu | Fe | Ni | Cr | Al | Ti | |
| Incoloy | 0.10 max | 1.50 max | 1.00 max | 0.015 max | 0.75 max | 39.50 min | 30.00 – 35.00 | 19.00 – 23.00 | 0.15 – 0.60 | 0.15 – 0.60 |
| Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation | |
| Incoloy Flanges | 7.94 g/cm3 | 1385 °C (2525 °F) | Psi – 75,000 , MPa – 520 | Psi – 30,000 , MPa – 205 | 30 % |
At Themban Nickel Alloys, we take pride in being the largest supplier, exporter, and manufacturer of Incoloy 800/800H/800HT Flanges in Cape Town , South Africa, providing cutting-edge solutions for all your piping needs. Our state-of-the-art production plants are strategically located in the Cape Town, allowing us to maintain a vast inventory of over 16,000 tons of premium-quality materials readily available in stock. We are dedicated to delivering superior products and services, ensuring reliability and excellence for our global clientele.
Contact us to get a quick quote for your requirement.
Incoloy 800, 800H, and 800HT flanges find extensive application in industries demanding high strength and resistance to heat. They are generally mounted in piping systems for heat exchangers, reactors, superheaters, and furnace parts in chemical and petrochemical plants. In power generation, the flanges find application in boiler headers and nuclear steam systems due to high operating temperature stability. The oil and gas industry also depends upon these flanges to function in high-temperature, high-pressure applications. Due to their corrosion resistance and durability, they are the most suitable for long-term operation at severe chemical and thermal conditions.
