Themban Nickel Alloys is a leading manufacturer and supplier of Super Duplex ball valves in Cape Town , South Africa. Our super duplex ball valves are designed to deliver excellent strength, superior durability and superior corrosion resistance, making them ideal for the most demanding industrial applications These valves excel in high pressure systems, aggressive chemicals and extreme temperatures so for reliable operation and long-term stability There is no doubt that it is widely used in chemical manufacturing, offshore oil and gas industry and power industry. We adhere to strict quality standards to ensure each valve meets stringent industry requirements. Choose Themban Nickel Alloys for premium super duplex ball valves that deliver exceptional quality and accuracy for your specific needs.
If you’re looking for top-notch Super Duplex Ball Valves, look no further than Themba Nickel Alloys, a reputable manufacturer based in Cape Town, South Africa. They’ve built a solid reputation for precision engineering and maintaining strict quality standards. Their valves are crafted to handle even the toughest industrial conditions. With a perfect blend of corrosion resistance and mechanical strength, these Super Duplex Ball Valves are designed to perform reliably in aggressive and high-pressure environments. Themba Nickel Alloys prioritizes durability, performance, and safety, ensuring their ball valves meet global industrial standards, making them a great fit for critical applications in the chemical, petrochemical, and offshore sectors.
| VALVES SIZE | 6 MM TO 50 MM and 1/8″ TO 2″ |
| STANDARD | ASME B 16.10, BS1414/API 600, ASME B 16.5, BS EN 12266-1/API 598, ASME B 16.34, ASTM A890 4A, ASME B 16.25 |
| CONNECTION | TUBE END, THREADED, SOCKET WELD, BUTT WELD, FLANGED, WELD NIPPLE, SAE |
| THREAD | METRIC, BSPP, NPT, JIC, BSPT, UNF |
| FUNCTION | 2 , 5 , 4 , 3 WAY, |
| MATERIAL OF SEAL RING | PVDF, DELRIN, GRAPHITE, PTFE, PEEK, |
| PRESSURE RATING | 15000 , 3000, 1500 , 10000, 6000 , 20000 PSI |
| TEMPERATURE OF MEDIA | (-120* C – 500*C ) AS LIKE PRESSURE RANGE |
| STANDARD | DIN , ISO , API , ANSI , AWWA , ASME , MSS |
| MEDIA | AIR, CHEMICAL, GAS, WATER, STEAM, HOT WATER , HYDRAULIC OIL, COLD WATER, SEA WATER |
| TYPE OF BODY | BAR STOCK |
| EQUIVALENT BRANDS | OLIVER VALVES, PARKER, SWAGELOK, HAMLET, DK-LOK, HOKE |
| PACKING DETAILS | WOODEN PALLET, BOX PACKING |
| Grade | S32760 | S32750 |
| Mn | 1.00 max | 1.20 max |
| Fe | 57.61 min | 58.095 min |
| C | 0.05 max | 0.030 max |
| Si | 1.00 max | 0.80 max |
| S | 0.010 max | 0.020 max |
| P | 0.030 max | 0.035 max |
| Cr | 24.00 – 26.00 | 24.00 – 26.00 |
| Ni | 6.00 – 8.00 | 6.00 – 8.00 |
| Mo | 3.00 – 4.00 | 3.00 – 5.00 |
| N | 0.20 – 0.30 | 0.24 – 0.32 |
| Melting Point (°C) | 1350 |
| Density (lb/in 3) | 0.281 |
| Density (g/cm 3) | 7.8 |
| Melting Point (°F) | 2460 |
What sets Themba Nickel Alloys’ Super Duplex Ball Valves apart is their unique microstructure, which consists of about 50% austenite and 50% ferrite, along with a rich mix of chromium (24–26%), nickel (6–8%), and molybdenum (3–5%). This special composition gives them exceptional resistance to pitting, crevice corrosion, and stress corrosion cracking. Plus, they boast impressive mechanical strength, with tensile strength between 850–950 MPa and yield strength of 550–650 MPa, all while ensuring excellent toughness, impact resistance, and durability. These superior material properties guarantee reliable performance, even in high-temperature and chloride-rich environments.
Contact us to get a quick quote for your requirement.
Super Duplex Ball Valves are a go-to choice in industries where safety, reliability, and corrosion resistance are non-negotiable. They’re perfect for chemical and petrochemical plants, oil and gas pipelines, desalination facilities, offshore platforms, and marine engineering projects. These valves provide precise flow control under high pressure and corrosive conditions, making them essential for critical infrastructure and industrial systems. With Themba Nickel Alloys’ Super Duplex Ball Valves, you can count on long-term operational reliability, safety, and efficiency, even in the most challenging environments.
